Product Details:
|
| Product Name: | Chloride Removal Adsorbent | Appearance: | White Or Grey-white Extrudates |
|---|---|---|---|
| Packing Density, Kg/l: | 0.75-0.85 | Chemical Composition: | Alkaline-earth Metal And Promoters |
| Particle Size, Mm: | Ф4×5-15 | Crushing Strength, N/cm: | Min50 |
| High Light: | HTCR-H Chloride Removal Adsorbent,Chloride Removal Chemical Catalyst |
||
Chloride removal adsorbent for reformering hydrogen off-gases, synthesis-gas,natural gas, naphtha, and light liquid hydrocarbons
chloride removal adsorbent is an outstanding adsorbent most commonly used in adsorbing hydrogen chloride from reformer hydrogen off-gases, synthesis-gas,natural gas, naphtha, and light liquid hydrocarbons in wide-temperature range applications(ambient up to 400℃).its chloride pick-up capacity rises with operating temperature.
It can provide 20% to 25% chloride pick-up capacity at 25℃ ,and over 50% at 300℃.
HTCR-H has been successfully used in a lot of industry plants of PETROCHINA and SINOPEC.
Physical and chemical properties:
| item | target | item | target |
| Appearance | white or grey-white extrudates | Particle size, mm | Ф4×5-15 |
| Packing density, kg/l | 0.75-0.85 | Crushing strength, N/cm | min50 |
| Chemical composition | alkaline-earth metal and promoters | Chloride capacity, | 25℃,min 20wt%HCI 300℃, min50wt%HC |
normal operating conditions:
Process parameters |
pressure ,Mpa | temperature,℃ | Space velocity,hr-1 |
| 0.1-8.0 | -5to400℃ | 3.0-10.0(L),500-3000(G) | |
| Raw material | HCI content, 1000 ppm | ||
| processed products | HCI content, max 0.1 ppm | ||
Packing: iron drums innerlining double-layer plastic bags.
