Extrudate Nickel Copper Desulfurization Catalyst

Extrudate Nickel Copper Desulfurization Catalyst
Extrudate Nickel Copper Desulfurization Catalyst

Large Image :  Extrudate Nickel Copper Desulfurization Catalyst

Product Details:
Place of Origin: China
Brand Name: JIULONG
Model Number: JL-LY-9
Payment & Shipping Terms:
Minimum Order Quantity: 1000g
Price: negotiation
Packaging Details: 40kg net weight iron drums innerlining double-layer plastic bags.
Delivery Time: negotiation
Payment Terms: L/C, T/T
Supply Ability: 700MT per month

Extrudate Nickel Copper Desulfurization Catalyst

Description
Product Name: Nickel- Copper Desulfurization Adsorbent Appearance: Appearance Gray And Black Extrudate
Particle Size/mm: ∮4×4-15 Copper Oxide ,%, ≥: 30
Nickel Oxide ,%, ≥: 10.0 Bulk Density, Kg/l: 0.8-1.0
Radial Crushing Strength, N/cm ≥: 180 Reduced Radial Crushing Strength, N/cm ≥: 100
Surface Area M2/g ≥: 70
High Light:

Nickel copper desulfurization catalyst

,

black extrudate desulfurization catalyst

                                               Nickel- copper desulfurization adsorbent for remove arsenic and chlorine







Nickel- copper desulfurization adsorbent carries nickel and copper as main active components ,with special alumina as carrier and dispersant. In normal condition, It is reduced state. We provide oxidized or reduced state according to customer’s requirement. In addition to the effective removal of sulfur compounds, Nickel- copper desulfurization adsorbent sulfur protective agents can remove arsenic and chlorine. With this catalyst, the sulfur, arsenic, chlorine and other impurities is considerably reduced 0.2ppm - 0.5ppm.
Characteristics:
1. The high depuration. under the process condition of 200℃,0.7-0.8Mpa ,6-8h-1,the sulfur content can be reduced to less than 0.2 ppm from 5 ppm. If the sulfur content of raw materials is100ppm, the sulfur content can be reduced to less than 0.5ppm.
2. HTSR-1 is not only removal of hydrogen sulfide and other inorganic sulfur, but also organic sulfur
3. The product can remove arsenic and chlorination.
4. Because of the high strength, hard powder, and easy operation. It is a kind of ideal protection agent of precious metal catalyst
Physical and chemical properties:

Item index
Appearance gray and black extrudate
Particle size/mm ∮4×4-15
copper oxide ,%, ≥ 30
nickel oxide ,%, ≥ 10.0
Bulk density, kg/l 0.8-1.0
Radial Crushing Strength, N/cm ≥ 180
Reduced radial crushing Strength, N/cm ≥ 100
Surface area m2/g ≥ 70

Reference operating conditions:


Process conditions
Temperature,℃ Pressure, Mpa Space velocity,hr-1
80-220( normal 80-200) ambient -1.5(normal 0.7-0.8) Gas:100-1000 Liquid :0.5-10.0
normal liquid space velocity 5-8
H2S In raw material 100ppm ≤0.5ppm;Breakthrough sulfur capacity:≥8%
Arsenide in raw material 100ppb ≤1ppb
chloride in raw material 10ppm ≤0.5ppm

Packing: 40kg net weight iron drums innerlining double-layer plastic bags.
