Product Details:
|
Product Name: | Sulfide-removal Adsorbent | Appearance: | Brown –red Extrudates |
---|---|---|---|
Particle Size/mm: | Φ (4.0±0.3) ×(5~20) | Bulk Density/kg·L-1: | 0.80~0.90 |
Crushing Strength/N·cm-1 ≥: | 80 | Temperature/℃: | Ambient -temperature |
Operating Pressure/MPa: | Ambient-pressure~4.0 | Volume Space Velocity, Hr-1: | ≤1500 |
Diameter Ratio: | 3~6 | ||
Highlight: | hydrotreating catalyst,solid phosphoric acid catalyst |
Appearance | Brown –red extrudates |
Particle size/mm | Φ (4.0±0.3) ×(5~20) |
Bulk density/kg·L-1 | 0.80~0.90 |
Crushing strength/N·cm-1 ≥ | 80 |
Reference operating conditions
Temperature/℃ | Ambient -temperature |
Operating pressure/MPa | Ambient-pressure~4.0 |
Volume Space velocity, hr-1 | ≤1500 |
Diameter ratio | 3~6 |
H2S content of inlet/mg·m-3 | ≤5000 |
H2S content of outlet/ mg·m-3 | ≤0.1 |
Going through Sulfur pick-up capacity/% | ≥20 |
Package and storage
1. the product is packed in paper drum lined inside with plastic bags. Net weight of a drum is 40kg.
2. Damaged packing and rain should be avoided during transportation.
3. The product can be stored for 3 years in ambient temperature in cool and dry place.
