Product Details:
|
| Product Name: | Arsine Removal Adsorbent | Appearance: | Black Tablet |
|---|---|---|---|
| Crush Strength,N/cm: | Min 150 | Chemical Compositions: | CuO-ZnO-AI2O3 And Promoters |
| Particle Size, Mm: | ∮5×5 | Bulk Density ,kg/l: | 1.15-1.35 |
| Arsenic Pick-up Capacity(wt%): | Min 15 | ||
| Highlight: | hydrotreating catalyst,solid phosphoric acid catalyst |
||
Arsine removal adsorbent for arsine removing from propylene ,ethylene, butylene and other chemical materials
It is widely used for arsine removing from propylene ,ethylene, butylene and other chemical materials.
Since being developed, it has been successfully applicated in more than 30 industry units in the world. All the users of JL-DC-5are very satisfied with its outstanding performance, such as high crushing strength, extraordinarily high arsenic pick-up capacity ,very good low temperature activity, low attrition loss, and the thorough arsenic removal capability.
its comprehensive performance is very superior to other same kind of industry products all over the world.
The outlet arsenic content can be decreased from about 10000ppb to less than 5ppb.
chemical and physical properties:
item |
Target | item | Target |
| appearance | Black tablet | Particle size, mm | ∮5×5 |
| Crush strength,N/cm | min 150 | Bulk density ,kg/l | 1.15-1.35 |
| Chemical compositions | CuO-ZnO-AI2O3 and promoters |
Arsenic pick-up capacity(wt%) |
min 15 |
Typical operating conditions:
Operating conditions |
pressure,Mpa | temperature,℃ | Liquid Space velocity , hr-1 |
| 1.0-4.0 | 20-40 | 2.0-6.0 | |
| Unprocessed propylene | Arsenic content ,10000ppb；reactive sulfur content,5ppm；water content,50ppm | ||
| Processed propylene | Arsenic content ,less than 20ppb(normal less than 5ppb)；arsenic removal rate, over 99%. | ||
Packing : 50KGS drums with plastic bag .
