Product Details:
|
| Product Name: | Methyl Ethyl Ketone By Hydrogenation Catalyst | Shape: | Cylinder |
|---|---|---|---|
| Size，mm: | φ5×4~5 | Component: | CuO-ZnO-Al2O3- Modifier |
| Pore Volume，mL/g: | 0.15~0.20 | Specific Surface Area /m2/g: | ≥80 |
| Bulk Density，g/mL: | 1.45-1.55 | Strength，N/CM: | ≥ 200 |
| High Light: | hydrotreating catalyst,solid phosphoric acid catalyst |
||
Methyl ethyl ketone by hydrogenation catalyst with better activity and selectivity
The catalyst has good thermal stability.Industrial application results show that the catalyst has better activity and selectivity,the temperature of the catalyst bed is 200～280℃,the operating pressure is lower than 0.5MPa,feed butanol LHSV under the condition of less than 6.0h-1,The average single pass conversion rate of SEC butyl alcohol is more than 75%,The selectivity of methyl ethyl ketone is greater than 98%;
Physical and chemical properties:
| item | index |
| shape | cylinder |
| size,mm | φ5×4~5 |
| Component | CuO/ZnO- carrier -modifier |
| pore volume,mL/g | 0.20-0.25 |
| specific surface area /m2/g | ≥80 |
| Bulk density,g/mL | 1.45-1.55 |
| strength,N/CM | ≥ 200 |
process conditions:
| item | index |
| Reaction inlet pressure,MPa | 0~0.2 |
| temperature,℃ | 220~270 |
| The raw liquid volume space velocity(LHSV),h-1 | 3.0~5.0 |
| SEC butanol single pass conversion,mol% | ≥ 75 |
| Methyl ethyl ketone selectivity,mol% | ≥ 98.5 |
| Methylheptenone selective,mol% | ＜ 1.0 |
| C4 hydrocarbon selectivity,mol% | ＜ 0.5 |
| Catalyst life, h | >12000 |
