Product Details:
|
CAS No.: | 1344-28-1 | Bulk Density: | 0.5-0.65g/cm3 |
---|---|---|---|
Cush Strenght: | Min 80N | Application: | Selective Hydrogenation Catalyst |
LOL: | 10 | Fe: | 0.03 |
Highlight: | catalyst support balls,alumina supported catalysts |
Catalyst QSH-01 is a kind of Palladium based noble metal catalyst, suitable for selective hydrogenation of dienes in C4 alkylation feedstock into monoolefin .It has excellent mechanical strength, activity, selectivity, stability, strong sulfur tolerance as well as long service life For the hydrogenation of highly-unsaturated C3 - C6 hydrocarbons from in other feedstock , the catalyst also has high selective hydrogenation ability . Its performances stand at international advanced level, and it’s in the leading position in domestic industry.
rType | Component | Appearance | Size mm |
Bulk Density g/cm3 |
BET
m2/g |
Pole Volum cm3/g |
Crush stength
N/Grain |
Na2O % | Al2O3 % | Water adsorption
% |
HYZ-001 | Al2O3•nH2O | Column | 3×(4-10) | 0.55-0.65 | ≥150 | ≥0.50 | ≥100 | ≤0.10 | ≥94 | ≥70 |
HYZ-002 | Al2O3•nH2O | clover | 3×(4-10) | 0.55-0.65 | ≥150 | ≥0.50 | ≥100 | ≤0.10 | ≥94 | ≥70 |
HYZ-003 | Al2O3•nH2O | Column | 3×(4-10) | 0.5-0.6 | ≥220 | ≥0.60 | ≥90 | ≤0.10 | ≥94 | ≥70 |
HYZ-004 | Al2O3•nH2O | clover | 3×(4-10) | 0.5-0.6 | ≥220 | ≥0.60 | ≥90 | ≤0.10 | ≥94 | ≥70 |
HYZ-005 | Silicon aluminum composite | Column | 3×(4-10) | 0.5-0.6 | ≥180 | ≥0.50 | ≥100 | ≤0.10 | ≥84 | ≥65 |
HYZ-006 | Silicon aluminum composite | Clover | 3×(4-10) | 0.5-0.6 | ≥180 | ≥0.50 | ≥100 | ≤0.10 | ≥84 | ≥65 |
HYZ-007 | Titaniumaluminum composite | Column | 3×(4-10) | 0.55-0.65 | ≥150 | ≥0.45 | ≥90 | ≤0.15 | ≥84 | ≥72 |
HYZ-008 | Titaniumaluminum composite | Column | 3×(4-10) | 0.55-0.65 | ≥150 | ≥0.45 | ≥90 | ≤0.15 | ≥84 | ≥72 |
HYZ-009 | Al2O3•nH2O | Column | 3×(4-10) | 0.70-0.80 | ≥180 | ≥0.40 | ≥80 | ≤0.10 | ≥94 | ≥50 |
HYZ-010 | Al2O3•nH2O | Sphere | Φ3-4 | ≥0.68 | ≥170 | ≥0.45 | ≥70 | ≤0.20 | ≥94 | ≥65 |
HYZ-011 | Al2O3•nH2O | Sphere | Φ5-7 | ≥0.68 | ≥170 | ≥0.45 | ≥130 | ≤0.25 | ≥94 | ≥50 |
HYZ-012 | Al2O3•nH2O | Sphere | Φ4-6 | 0.55-0.60 | ≥250 | ≥0.45 | ≥60 | 0.10-1.00 | ≥94 | ≥60-70 |
HYZ-013 | Al2O3•nH2O | Clover | 3×(4-10) | 0.45-0.60 | ≥350 | ≥0.65 | ≥70 | ≤0.10 | ≥95 | ≥80 |
