Product Details:
|
| Color: | White Clover | Bulk Density: | 0.5-0.65g/cm3 |
|---|---|---|---|
| Cush Strenght: | Min 80N | LOL: | 10% |
| CL: | 90PPM | BET: | 100-300 |
| Highlight: | catalyst support balls,activated alumina balls |
||
characteristic
■ QSH-02 Selective Hydrogenation Catalyst has a unique crystalline structure, improve the dispersion of palladium, good catalyst activity and activity stability; at the same time having a butene isomerization performance;
■ QSH-02 Selective Hydrogenation Catalyst, high resistance to erosion ability, the active ingredient difficult to drain; renewable, long service life;
Suitable for the process of selective hydrogenation of highly unsaturated hydrocarbons in pyrolysis.
| rType | Component | Appearance | Size mm |
Bulk Density g/cm3 |
BET
m2/g |
Pole Volum cm3/g |
Crush stength
N/Grain |
Na2O % | Al2O3 % | Water adsorption
% |
| HYZ-001 | Al2O3•nH2O | Column | 3×(4-10) | 0.55-0.65 | ≥150 | ≥0.50 | ≥100 | ≤0.10 | ≥94 | ≥70 |
| HYZ-002 | Al2O3•nH2O | clover | 3×(4-10) | 0.55-0.65 | ≥150 | ≥0.50 | ≥100 | ≤0.10 | ≥94 | ≥70 |
| HYZ-003 | Al2O3•nH2O | Column | 3×(4-10) | 0.5-0.6 | ≥220 | ≥0.60 | ≥90 | ≤0.10 | ≥94 | ≥70 |
| HYZ-004 | Al2O3•nH2O | clover | 3×(4-10) | 0.5-0.6 | ≥220 | ≥0.60 | ≥90 | ≤0.10 | ≥94 | ≥70 |
| HYZ-005 | Silicon aluminum composite | Column | 3×(4-10) | 0.5-0.6 | ≥180 | ≥0.50 | ≥100 | ≤0.10 | ≥84 | ≥65 |
| HYZ-006 | Silicon aluminum composite | Clover | 3×(4-10) | 0.5-0.6 | ≥180 | ≥0.50 | ≥100 | ≤0.10 | ≥84 | ≥65 |
| HYZ-007 | Titaniumaluminum composite | Column | 3×(4-10) | 0.55-0.65 | ≥150 | ≥0.45 | ≥90 | ≤0.15 | ≥84 | ≥72 |
| HYZ-008 | Titaniumaluminum composite | Column | 3×(4-10) | 0.55-0.65 | ≥150 | ≥0.45 | ≥90 | ≤0.15 | ≥84 | ≥72 |
| HYZ-009 | Al2O3•nH2O | Column | 3×(4-10) | 0.70-0.80 | ≥180 | ≥0.40 | ≥80 | ≤0.10 | ≥94 | ≥50 |
| HYZ-010 | Al2O3•nH2O | Sphere | Φ3-4 | ≥0.68 | ≥170 | ≥0.45 | ≥70 | ≤0.20 | ≥94 | ≥65 |
| HYZ-011 | Al2O3•nH2O | Sphere | Φ5-7 | ≥0.68 | ≥170 | ≥0.45 | ≥130 | ≤0.25 | ≥94 | ≥50 |
| HYZ-012 | Al2O3•nH2O | Sphere | Φ4-6 | 0.55-0.60 | ≥250 | ≥0.45 | ≥60 | 0.10-1.00 | ≥94 | ≥60-70 |
| HYZ-013 | Al2O3•nH2O | Clover | 3×(4-10) | 0.45-0.60 | ≥350 | ≥0.65 | ≥70 | ≤0.10 | ≥95 | ≥80 |
